Introduction to the Respiratory System

Describe the components of the respiratory system

Breathing is an involuntary event. How often a breath is taken and how much air is inhaled or exhaled are tightly regulated by the respiratory center in the brain. Humans, when they aren’t exerting themselves, breathe approximately 15 times per minute on average. Canines, like the dog in Figure 1, have a respiratory rate of about 15–30 breaths per minute. With every inhalation, air fills the lungs, and with every exhalation, air rushes back out. That air is doing more than just inflating and deflating the lungs in the chest cavity. The air contains oxygen that crosses the lung tissue, enters the bloodstream, and travels to organs and tissues. Oxygen (O2) enters the cells where it is used for metabolic reactions that produce ATP, a high-energy compound. At the same time, these reactions release carbon dioxide (CO2) as a by-product. CO2 is toxic and must be eliminated. Carbon dioxide exits the cells, enters the bloodstream, travels back to the lungs, and is expired out of the body during exhalation.

An X-ray on the left shows a dog heart, which appears as a white, oblong mass, surround by virtually transparent lung tissue. The photo on the right shows a dog.

Figure 1. Lungs, which appear as nearly transparent tissue surrounding the heart in this X-ray of a dog (left), are the central organs of the respiratory system. The left lung is smaller than the right lung to accommodate space for the heart. A dog’s nose (right) has a slit on the side of each nostril. When tracking a scent, the slits open, blocking the front of the nostrils. This allows the dog to exhale though the now-open area on the side of the nostrils without losing the scent that is being followed. (credit a: modification of work by Geoff Stearns; credit b: modification of work by Cory Zanker)

What You’ll Learn to Do

  • Describe the passage of air from the outside environment to the lungs
  • Understand how gas pressure influences how gases move into and out of the body
  • Describe how the structures of the respiratory system control the mechanics of breathing
  • Explain how gases are transported in the body

Learning Activities

The learning activities for this section include the following:

  • Systems of Gas Exchange
  • Gas Exchange across Respiratory Surfaces
  • Breathing
  • Transport of Gases in Human Bodily Fluids
  • Self Check: Respiratory System
